Frame
Scale Carbon HMFAdjustable head angle / Syncros Cable Integration SystemAdvanced Shock & Standing Damping SystemBB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork
RockShox Judy Silver TK Solo Air15x110mm QR axle / 42mm offset / Tapered SteererReb. Adj. / Lockout / 100mm travel
Remote System
SCOTT RideLoc 2 Remote
Rear Derailleur
SRAM NX Eagle 12 Speed
Shifters
SRAM SX Eagle Trigger
Crankset
SRAM SX Eagle DUB55mm CL / 30T
BB-Set
SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain
SRAM CN SX Eagle
Cassette
SRAM SX-PG1210 / 11-50 T
Brakes
Shimano MT200 Disc Brake
Rotor
Shimano SM-RT10 CL / 180/F and 160/R
Handlebar
Syncros Alloy 6061T shape Flat / 9° / 700mmSyncros Performance XC lock-on grips
H'stem
Syncros Alloy 6061oversized 31.8mm / 1 1/8" / 6° angle
Seatpost
Syncros / 31.6x400mm
Seat
Syncros Savona 2.5 V-Concept
Headset
Syncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
Hub (Front)
Formula CL-811 / 15x110mm
Hub (Rear)
Formula CL-3248 / 12x148mm
Spokes
Stainless Black 15G / 1.8mm
Rims
Syncros X-30SE / 32H / 30mmTubeless ready
Front Tire
Schwalbe Smart Sam 29x2.35" / Active line
Rear Tire
Schwalbe Smart Sam 29x2.35" / Active line
Approx weight in KG
12.7 (Tubeless setup)
Approx weight in LBS
28 (Tubeless setup)
Max. System Weight
128kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
