Frame
Alpha Smooth Aluminium, Bosch Compact PowerTube, internal cable routing, post-mount disc, 135X5 mm QR
Fork
Trek alloy, threadless steel steerer, ThruSkew QR
Hub front
Shimano TX505, CenterLock
Skewer front
132x5 mm QR, ThruSkew
Hub rear
Shimano TX505, CenterLock
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Tyre
Bontrager H2 Comp, wire bead, 30 tpi, 27.5x2.00"
Max tyre size
27.5x2.00" with or without mudguards
Battery
Bosch CompactTube 400 Wh
Charger
Bosch standard 2A, 230V, smart system
Computer
Bosch LED remote, smart system
Motor
Bosch Active, smart system, 40Nm, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC)
Shifter
Shimano M315, 8-speed
Rear derailleur
Shimano Acera M3020-8, 40T max cog
Crank
ProWheel alloy, 170 mm length
Chainring
ProWheel 38T narrow/wide steel, w/alloy guard
Cassette
Shimano HG400, 11-40, 8-speed
Chain
KMC Z8.3
Pedal
slip-proof pedals with reflectors
Max. chainring size
1x: 40T
Saddle
Selle Royal Nuvola
Seatpost
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Handlebar
Bontrager aluminium touring
Grips
Herrmans Clik, ergonomic, lock-on
*Stem
Size: S, MBontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm lengthSize: LBontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
Brake
Shimano MT200 hydraulic disc
*Brake rotor
Size: S, M, LShimano RT70, CentreLock, 160 mmSize: S, M, LShimano RT10, CenterLock, 160 mm
*Light
Size: S, M, LHerrmans MR-GO, 100 lumen, 35 luxSize: S, M, LSpanninga SOLO for e-bike
Kickstand
Pletscher Comp 18
Cargo rack
MIK-compatible alloy rear rack
Mudguard
SKS wide, plastic
Weight
M - 19.80 kg / 43.66 lb
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
